PN

HG-PG-MB-V1-20210802

video input

High speed differential digital video

video output

USB2.0，UVC, mini HDMI;

The input connector

DF52-8P-0.8C

The output connector

Type C USB; mini HDMI

version for HW

HG-PG-MB-V1-20210802

version for FW

640x480_20210820_M0

Function

Image Preview

Camera parameter adjust include brightness/ contrast/ Hue/ saturability/ white balance/backlight contrast/ gain

The MTBF (mean time between failures)

At least 10000 hours

Input voltage range

3.5V~5V

The power consumption

Maximum current (included camera):200mA/5V;

Operating temperature;

–10℃ —— +50℃

size

60mm*20mm
