PN

HG-PD-V1

video input

0V6946 analog signal

video output

Micro SB2.0 400*400pixel 30fps MJPG

HDMI 1920x1080 @60fps

The input connector

SIP-6P 2.54mm

The output connector

Type C USB; mini-HDMI

version for HW

HG-PD-V1

version for FW

20210812

Function

Image Preview

Camera parameter adjust include brightness/ contrast/ Hue/ saturability/ white balance/backlight contrast/ gain

The MTBF (mean time between failures)

At least 10000 hours

Input voltage range

Micro USB 5V

The power consumption

Maximum current (included camera):500mA/5V;

Operating temperature;

–10℃ —— +50℃

size

50mm*20mm
