3.7mm
ITEM |
DESCRIPTION |
Camera Model NO |
03D3701 |
Camera Diameter |
3.7mm |
Camera Module Dimension |
3.7mmx18mm |
Camera Direction |
Front view ( 0°) |
Tube material |
Stainless steel |
Image device |
1/7.5” High Color Sensor |
Pixel Size |
3um x 3um |
Effective Picture Element |
640(H)X480(V) |
AGC |
Auto |
AES |
Auto |
AWB |
Auto |
Dynamic Range |
70.4 dB @ 8x gain |
S/N Ratio |
38dB |
Lens Construction |
2P + IR |
Lens F/NO |
F3.0 |
90° |
|
Lens Focus Range |
10mm – 100mm |
Light Source |
6pcs High Luminous White LED |
Power input |
DC 3.3V |
Output format |
Digital signal output |
Support for decoding boards |
USB decoding board or Hengal Universal mainboard |
Power Consumption |
TBD |
Operating Temperature |
-30°C to +70°C |
Operating Humidity |
30%~90%Rh |
Length of connectable wire |
Up to 5 Meters 6-core Teflon wire |
