ITEM

DESCRIPTION

Camera Model NO

02A2801

Camera Diameter

2.8 mm

Camera Module Dimension

2.8mmx5mm

Tube material

Stainless steel

Image device

1/18” High Color Sensor

Pixel Size

1.75µm x 1.75µm

Effective Picture Element

400(H)X400(V)

AGC

Auto

AES

Auto

AWB

Auto

Dynamic Range

65.8dB @ 4x gain

S/N Ratio

36.8dB

Lens Construction

3G + IR

Lens F/NO

F5.0

Lens View Angle (FOV D)

120°

Focus Range

5mm – 50mm

Light Source

4pcs High Luminous White Color LED

Power input

DC 3.3V

Output format

Analog signal output

Support for decoding boards

USB decoding board or 5-inch screen decoding board

Power Consumption

TBD

Operating Temperature

-20°C to +70°C

Operating Humidity

30%~90%Rh

Length of connectable wire

4 Meters 6-core Teflon wire
