ITEM

DESCRIPTION

Camera Model NO.

02A2101

Camera diameter

2.1 mm

Camera Module Dimension

2.1 mmx5.0 mm

Tube material

Stainless steel

Image device

1/18” High Color Sensor

Pixel Size

1.75µm x 1.75µm

Effective Picture Element

400(H)X400(V)

AGC

Auto

AES

Auto

AWB

Auto

Dynamic Range

65.8dB @ 4x gain

S/N Ratio

36.8dB

Lens Construction

3G + IR

Lens F/NO

F5.0

Field of Viewing (FOV)

120°

Focus Range

5mm – 50mm

Light Source

4pcs High Luminous White Color LED

Power input

DC 3.3V

Output format

Analog signal output

Support for decoding boards

USB decoding board or Hengal universal mainboard

Power Consumption

TBD

Operating Temperature

-20°C to +70°C

Operating Humidity

30%~90%Rh

Length of connectable wire

Up to 4 Meters 6-core Teflon wire
