Product Description





INDUSTRIAL ENDOSCOPE SPEC.
Insertion Grip Specification- P6 series
Item No. C28-00-1 C60-22-1
Diameter 2.8mm with no channel 6mm
Channel Diameter NO CHANNEL 2.2mm
Articulation Way Two-way articulation Two-way articulation
Accessory NO forceps & pliers
CMOS SENSOR CMOS sensor 1/18" CMOS sensor 1/18"
400 x400 pixels 400 x400 pixels
Direction of view front ( 0 °)
Depth of field 5-50mm
Field of Viewing 120°
Light Source 4 white LED 2 white LED
Insertion probe length  1 meter
Highlight Compensation & Backlight Compensation YES
Insertion Probe Material Wear-resistant metal braided tube
Waterproof IP67
Operate Temperature -10°C to 50°C

Monitor Specification- P6 series
• Display 4.0 ”IPS full-view LCD screen
• Display resolution 480(RGB)*480
• Touch Panel YES
•Hight Light Compensation (HLC) Two levels of HLC(apply when inspect reflective surface )
• Back Light Compensation (BLC) Two levels of BLC(apply when inspect distant perspective)
• Image Mirror and Rotation 180° mirror and rotation
• Zoom 4x digital zooming
• Image Freeze YES
• Photo JPEG resolution: 400*400
• Video MP4 H.264 Resolution: 400*400
• USB Interface micro USB 2.0,charging interface DC 5V; data transmission
• TV Out HDMI
• Storage Micro SD card (up to 32GB )
• Battery Rechargeable li-ion battery 18650 (3.7V) 3400mAH
• Battery Life (typical) ≥5 hours
•  Tool Case Professional portable tool case with EVA padding
